Editing Colors

This section provides an overview of the core color editing features in Phoenix Code.

Inline Color Editor​

Inline Color Editor lets you edit colors directly inside Phoenix Code using a color picker.

Accessing the Inline Color Editor​

To open the Inline Color Editor just hover over the color you want to edit. Inline Color Editor

The Inline Color Editor provides you an Edit button, click on it to open the color picker. Color Picker

Understanding the Color Picker Dialog​

The Color Picker dialog lets you edit the colors visually. Here are the key components:

  • Color Spectrum: The square on the left adjusts the brightness and intensity of the color. Drag the circle to select a specific shade.

  • Hue Slider: The vertical slider adjusts the main color (hue). Move it up or down to switch between colors like red, green, or blue.

  • Transparency Slider: The checkered slider adjusts the Alpha(transparency) of the color. Move it to set the color between fully solid and fully transparent.

  • Color Preview: On the top right, you’ll see a Color Preview. The preview is divided into two parts:

    • Right Side: Displays the new color being selected. It dynamically updates as you adjust the controls.
    • Left Side: Displays the original color before editing.

  • Color Suggestions: On the right, a list of already used colors in the file are displayed. Hovering over a color shows how many times it has been used in the file. This helps you pick consistent colors without needing to remember their codes.

  • Code Format Selection: Below the Color Spectrum we have the option to switch between different formats:

    • RGBA: Red, Green, Blue, and Alpha(transparency).
    • Hex: Standard hexadecimal color code.
    • HSLa: Hue, Saturation, Lightness, and Alpha.
    • Hex 0x: Hexadecimal format with a 0x prefix, such as 0xFF5733.

  • Input Field: At the bottom of the dialog, you can type in specific color values directly (e.g., #FF5733, rgb(255, 87, 51, 1), orange).

Visual Reference​

Color Preview​

The Color Preview feature displays the color(s) used in the current line in the gutter area. Color Preview

A maximum of four colors can be displayed for a single line.

Hover Interaction​

  • Hovering over a color box highlights the corresponding color text in the editor with a background of the same color.
  • If a container has multiple colors, the hovered color box enlarges for easier accessibility, and its color text gets highlighted with the same color. Color Preview Hover

Click Behavior​

Clicking a color in the gutter moves the cursor to its position in the editor and opens the Color Picker for editing.

Enabling/Disabling Color Preview​

You can enable/disable the feature by updating the colorPreview property in the preferences file. Click Here to read on how to edit the preferences.
